Infineon IPP60R070CFD7 650V CoolMOS™ CFD7 Power Transistor: Advanced Performance for High-Efficiency Applications

The Infineon IPP60R070CFD7 is a state-of-the-art 650V superjunction MOSFET from the revolutionary CoolMOS™ CFD7 family, engineered to deliver exceptional efficiency and reliability in high-performance power conversion systems. Designed with a focus on reducing both switching and conduction losses, this transistor sets a new benchmark for power density and thermal management in applications ranging from server SMPS and telecom bricks to industrial motor drives and renewable energy inverters.

A key highlight of the IPP60R070CFD7 is its ultra-low on-state resistance (RDS(on)) of just 70 mΩ, significantly minimizing conduction losses even at high load currents. Combined with an optimized charge balance and advanced packaging technology, the device achieves superior switching performance, enabling higher operating frequencies without compromising thermal behavior. This allows designers to reduce the size of passive components such as inductors and transformers, leading to more compact and cost-effective power supplies.

Another standout feature is its integrated fast body diode, which enhances hard-switching performance and improves reliability in bridge topologies like PFC, half-bridge, or full-bridge circuits. The diode offers low reverse recovery charge (Qrr) and soft reverse recovery characteristics, reducing EMI and voltage overshoot. This makes the CFD7 series particularly suitable for resonant topologies like LLC converters, where diode behavior critically impacts efficiency.

Thermal performance is also a major strength. The IPP60R070CFD7 is offered in a TO-220 full-pack (FP) package that provides improved creepage distance and superior isolation characteristics. The package ensures enhanced thermal conductivity, allowing better heat dissipation and higher power throughput in a given form factor.

Moreover, the CoolMOS™ CFD7 technology incorporates robustness and durability features including high avalanche ruggedness and improved immunity against gate voltage fluctuations. These attributes make it an ideal choice for demanding environments where overvoltage and overcurrent conditions may occur.

In summary, the IPP60R070CFD7 represents a significant leap in high-voltage power transistor technology, offering system designers a compelling combination of efficiency, power density, and reliability.

ICGOOODFIND

The Infineon CoolMOS™ CFD7 IPP60R070CFD7 is a groundbreaking power transistor that excels in high-efficiency and high-frequency applications. Its ultra-low RDS(on), integrated fast body diode, and excellent thermal performance make it a top choice for next-generation power supplies and motor control systems.

---
